藍牙協(xié)議分析儀  支持抓包（藍牙BLE+WiFi）Ellisys BTR1

Bluetooth Low Energy and Wi-Fi Protocol Analyzer




Key Points:
¡ All-in-One: wired and wireless, concurrently, perfectly synchronized
¡ Wideband Capture: easy and rock-solid capture of all Bluetooth Low Energy channels
¡ Reprogrammable Digital Radio: ready today for tomorrow’s specifications
¡ Wi-Fi: debug your Wi-Fi a/b/g/n and BLE connections simultaneously, as well as coexistence
¡ Raw Spectrum Capture: characterize the wireless environment and visualize interferences
¡ Logic Analysis: visualize digital signals such as GPIOs, interrupts, debug ports, etc.
¡ Extremely Compact: pocket-sized at 7.5 x 7.5 x 1.7 cm (2.9 x 2.9 x 0.7')
¡ USB Powered: portable, convenient and environmentally friendly
¡ All Protocols and Profiles: best-of-breed protocol decoding
¡ Free Maintenance: never a charge for software updates, free fully-featured viewer






Technical Specifications:
Bluetooth Capture Characteristicsn Ellisys Rainbow?: Wideband, concurrentcapture of all BLE channelsn Frequency band: 2.402-2.480 GHzn Sensitivity range: From -90 to +15 dBmn Gain: Programmable from -30 to +15 dBn Modulations: All BLE modulations (GFSK1 Mbps and 2 Mbps)n Baseband: Support of Bluetooth 5,upgradeable by software

Wi-Fi Capture Characteristicsn 802.11 a/b/g/nn Channel width 2.4GHz: 20 MHzn Channel width 5GHz: 20 MHzn 11n MCS 2.4 GHz 20 MHz channel: 0 to 7n 11n MCS 5 GHz 20 MHz channel: 0 to 7

Logic Capture Characteristicsn Maximum bandwidth: 50 MHzn Sampling precision: 5 nsn Supported input voltage: 1.8 to 3.3VHCI Capture Characteristicsn UART / SPI transports: Up to 8 Mbit/s,automatic detection of all parameters

Embedded Memory n 128 MB of FIFO memory n Data is stored in highly optimized format n Analyzed data is uploaded in real timethrough USB 2.0 connection Timing n Clock: ±10 ppm frequency accuracy over -10 to +60 degrees Celsius range n BLE timestamp accuracy: 125 ns n Wi-Fi timestamp accuracy: 1 us n Logic timestamp accuracy: 5 ns Connectors n Capture: Standard SMA female n Logic: 16 logic signals n Sync: Multi-unit synchronization ports n Control: USB 2.0 connection to control PC n Power: Optional 5V power input, max 3W Enclosure n 75 x 75 x 17 mm (2.9 x 2.9 x 0.7') n 100 g (0.2 lbs)
